Alpine SWS-10D2 2 ohm subwoofer

10″ 1500w (peak) S-type subwoofer


The all-new Type-S subwoofers are more durable and powerful than ever, delivering accurate ground pounding bass. With their new sleek design, they look as great as they perform.

They are ready for virtually any system type desired, and have a shallow design which allows installation even in difficult locations.


Material: Oversized Hairline-Textured Mica Poly Dustcap w/ Kevlar Reinforced Pulp Paper Cone Body
Design: 2-Piece Parabolic

Material: Injected Molded Santoprene
Design: High Amplitude Multi-Roll H.A.M.R Surround Design (Patent Pending)

Material: ConexA? Design: 10 Segment High-Roll Progressive Design

Voice Coil
Material: 180A High Temp Wire on Spiral-Cut Aluminum Bobbin Design: 5-Layer Split-Winding Dual Voice Coil

Motor Structure
Pole Geometry: FEA Optimized Underhung Design w/ Dual-Sided Compound Radius Pole Geometry
Configuration: Dual Flared Design w/ Integrated Backplate Venting

Material: 18GA High Strength Steel
Design: Alpine-Designed 5 Leg Structure w/ Integrated Radial Voice Coil Vents

Layout: One Sided
Design: 8ga. Push Terminals

Tinsel Leads
Design: Reinforced-Layer Spider Integration
Design: Concealed Mount Gasket System


Power Handling
Power Range: 150W – 500 Watts
RMS Power Handling: 500W
Peak Power Handling: 1500W

Mounting Depth: 177mm (7”)
Mounting Diameter: 347mm (13.7”)
Displacement: 0.07 cu. Ft.
Added Volume: 0.15 cu. ft. (Reverse Mount, Magnet Out)

Frequency Response: 24Hz – 200Hz
Recommended Enclosure Sizes
– Sealed enclosure: 17.0L
– Vented enclosure: 39.6L
